Rated volume

5000L

Tank size (

3700×1800×1200mm

Rated contained mass

3600kg

curb weight

3630kg

Divide warehouse

Tongcang

tank form

Oval horizontal type, integrated with car tank

Tank material

SUS304-2B food grade

Liner thickness

δ3.0 mm

Outer cover thickness

δ1.0mm

Milk outlet diameter

∮51mm national standard/non-standard

Insulation Materials

70 mm polyurethane spray

+10mm rubber plastic insulation cotton

Insulation performance

Using polyurethane spray foam, the thermal   insulation performance does not exceed 2℃ for 24 hours

Tank head

Single layer flat head

Thickness 3.5 mm

Cleaning method

CIP automatic cleaning, each warehouse is   equipped with cleaning balls to meet 360° cleaning   requirements

Car chassis

Dongfeng Dolica D 6 chassis, wheelbase 3308 mm,   YCY24140-60 Yuchai 1 40- horsepower National VI engine, Wanliyang 6-speed   gearbox, 7.00R16 wire tires, air brakes, with A BS , air conditioning,   electric glass;

Remark

1. The milk discharge switch and cleaning   switch are made into a cluster structure, and the number of each milk bin is   marked . Before the vehicle leaves the factory, the transport medium and   announced volume are sprayed on the tank according to the announcement   requirements;

2. Tank volume 4700 L;

3. The rear operation box adopts gas spring   hatchback type opening and is equipped with an opening handle;

4. Each manhole cover and rear tool box are   equipped with a lead sealing device to facilitate the management of the milk   truck when loading and unloading fresh milk;

5. Equipped with a movable ladder for personnel   to enter and exit the tank;

6. Through-silo design , no support plate,   one ∮ 500 mm food-grade tank mouth;

7. There are two automatic cleaning balls in   the warehouse, controlled by one valve, and the valve interface is ∮ 51 mm.
