engine model

4KB1-TCG60

Engine horsepower (PS)

130

Auxiliary engine horsepower (PS)

JMC 87/Qingfa 88 (optional)

The box has a water tank volume

1 water/4 dust (m³)

Capacity of box without water tank

5m³dust

Overall dimensions (length × width × height)

6 6 00*2 020 0*2 73 0( mm)

Front   suspension/rear suspension (mm)

1015/1770

Maximum total mass (kg)

73 0 0

Curb weight (kg)

5 750

Rated load mass (kg)

1420

Maximum cleaning width (m)

2.5

Maximum cleaning capacity (㎡/h)

36000

Cleaning speed (km/h)

5-20

Cleaning speed (km/h)

15-20

The electromagnetic valve

The   Hypress solenoid valve group is the core component of the vehicle hydraulic   system. It controls the hydraulic drive of the entire vehicle and the two-way   operation buttons, including a series of mechanical operations such as   sweeping plate lifting, suction cup lifting, garbage bin lifting, and rear   door opening and closing. The vehicle is equipped with There is a solenoid   valve to control the box cover, which effectively prevents dust and garbage   from entering the box.

fan

The   auxiliary engine and the fan are the two core components of the sweeper. The   auxiliary engine provides power for the operation of the fan, so that road   garbage is sucked into the box and stored inside, thereby achieving road   cleaning operations. The fan adopts high-power wear-resistant centrifugal   maintenance-free fan, which is noise-free, high efficiency, large air volume   and long service life.

automatic clutch

Reduce   the impact on the engine when the fan starts and stops. The clutch has the   advantages of high wear resistance, long service life, low noise, low fuel   consumption and cost saving during use .

suction cup

The   suction cup has a built-in roller sweeper to effectively clean up road   debris.

filter element

Vertical   filter cartridge for easy cleaning and disassembly

Auxiliary engine

The   auxiliary engine provides power for the operation of the fan.

Side brush

Increase   the working width and effectively sweep the garbage into the suction cup   position.

Electronic diaphragm pump:

Control   the tail water spray lever to spray water to suppress dust.

emergency system

The   entire vehicle hydraulic system can be controlled through a manual emergency   hydraulic pump.

tail spray

After   the operation is completed, dust is suppressed at the tail.
