SINOTRUK Duty Truck

Total mass :

18000kg

Rated load quality :

5170kg

Curb weight :

12700kg

Chassis model:

ZZ1187K501GF1

Type:

4×2 , flat-head diesel vehicle

engine model:

MC05H.20-60

Engine maximum power :

147kW

Tail gas emissions:

Euro 3

Wheelbase:

4700mm

Cleaning part

Clean water tank volume:

5m³

Tank thickness:

8mm

High pressure pump brand

Yifeng

Flow volume / pressure

200L/150Bar

High pressure hose inner diameter

22mm

High pressure hose length

100m

nozzle

Ceramic nozzle four-piece set

Protection System

Low water electronic alarm

absorb dirt

Sewage tank capacity:

22m 3

Sewage tank cross- sectional shape

round

Tank thickness

8mm

Vacuum pump model:

Yifeng DB22

Vacuum pump flow rate :

2000m³/h

When the tank is full

≤5min

suction lift

≥ 18m

Inlet / discharge valve port diameter

5H / 6H

Rear tank door opening method

Hydraulic opening

Protection System

Four-level protection system ( first -level anti-overflow valve, cyclonic second - level stop valve, anti-overflow cut-off valve electronics

Anti-overflow alarm)

swivel boom

Can be moved forward and backward , up and down , left and right for remote control operation

sewage suction pipe

16m

Control system

Integrated electric control box, manual / remote control, simple and convenient , low learning cost
