The main technical parameters
Chassis | Overall size : | 8850×2500×3750mm |
Total mass : | 18000kg |
Rated load quality : | 6270kg |
Curb weight : | 11600kg |
Chassis model: | DFH1180EX8 |
Type: | 4×2 , flat-head diesel vehicle |
engine model: | B6.2NS6B210 |
Engine maximum power : | 154kW |
Tail gas emissions: | National VI |
Wheelbase: | 4700mm |
Cleaning part | Clean water tank volume: | 5m³ |
Tank thickness: | 6mm |
High pressure pump brand | Yifeng |
Flow volume / pressure | 200L/150Bar |
High pressure hose inner diameter | 22mm |
High pressure hose length | 100m |
nozzle | Ceramic nozzle four-piece set |
Protection System | Low water electronic alarm |
absorb dirt | Sewage tank capacity: | 8m 3 |
Sewage tank cross- sectional shape | round |
Tank thickness | 6mm |
Vacuum pump model: | Yifeng SK-15 |
Vacuum pump flow rate : | 2000m³/h |
When the tank is full | ≤5min |
suction lift | ≥ 18m |
Inlet / discharge valve port diameter | 5H / 6H |
part | How to lift the tank | Front cylinder lift |
Rear tank door opening method | Hydraulic opening |
Protection System | Four-level protection system ( first -level anti-overflow valve, cyclonic second - level stop valve, anti-overflow cut-off valve electronics Anti-overflow alarm) |
swivel boom | Can be moved forward and backward , up and down , left and right for remote control operation |
| sewage suction pipe | 16m |
Control system | Integrated electric control box, manual / remote control, simple and convenient , low learning cost |
