The main technical parameters
Chassis | Overall size : | 12000×2550×3980mm |
Total mass : | 31000kg |
Rated load quality : | 11170kg |
Curb weight : | 19700kg |
Chassis model: | ZZ1315V4666F1 |
Type: | 8×4 , flat-head diesel vehicle |
engine model: | MC07.34-60 |
Engine maximum power : | 251kW |
Tail gas emissions: | Euro 3 |
Wheelbase: | 1800+3775+ 1400mm |
Cleaning part | Clean water tank volume: | 11m³ |
Tank thickness: | 8mm |
High pressure pump brand | Yifeng |
Flow volume / pressure | 300L/200Bar |
High pressure hose inner diameter | 22mm |
High pressure hose length | 100m |
nozzle | Ceramic nozzle four-piece set |
Protection System | Low water electronic alarm |
absorb dirt | Sewage tank capacity: | 22m 3 |
Sewage tank cross- sectional shape | round |
Tank thickness | 8mm |
Vacuum pump model: | Yifeng DB22 |
Vacuum pump flow rate : | 3000m³/h |
When the tank is full | ≤5min |
suction lift | ≥ 20m |
Inlet / discharge valve port diameter | 5H / 6H |
part | How to lift the tank | Front cylinder lift |
Rear tank door opening method | Hydraulic opening |
Protection System | Four-level protection system ( first -level anti-overflow valve, cyclonic second - level stop valve, anti-overflow cut-off valve electronics Anti-overflow alarm) |
swivel boom | Can be moved forward and backward , up and down , left and right for remote control operation |
| sewage suction pipe | 16m |
Control system | Integrated electric control box, manual / remote control, simple and convenient , low learning cost |
