【 Technical Parameters 】 |
Product
trademark | Huatong
brand | product
name | Multifunctional
dust suppression vehicle |
Chassis
model | EQ1258GSZ6DJ | Product
number | CLW5181TDYD6 |
Axle
load(Kg) | 7000/18000
(two-axis group) | Maximum
speed (Km/h) | 89 |
Approach
angle/departure angle (°) | 29/12,29/13 | Front
suspension/rear suspension (mm) | 1475/3025,1515/2985 |
Number
of axes | 3 | Number
of tires | 10 |
Wheelbase | 4500,4700 | Tire
specifications | 10.00R20
18PR,275/80R22.5 18PR |
Number
of leaf springs | 8/10+8,9/12+10,3/4+3,3/10+8,8/10+7,9/10+8 | Fuel
type | diesel
fuel |
Front
wheelbase (mm) | 1880,1940,1965,1910,1810,1920 | Rear
wheelbase (mm) | 1820,1860,1800 |
engine
model | B6.2NS6B230 | Engine
manufacturer | Dongfeng
Cummins Engine Co., Ltd. |
Displacement
(ml) | 6200 | Power(Kw) | 1 69kw |
gearbox | Shaanxi Fast
8-speed gearbox | front/rear axle | 5T/10T |
Maximum
speed (Km/h) | 89 |
|
|
Other
configurations | Electronically controlled air conditioning, aluminum alloy wheels,
air brakes, LED daytime running lights, central locking, electric doors and
windows, remote control key, leather seats, LCD instrument panel, power
steering, clutch assist, exhaust brake, sunroof, aluminum Alloy fuel tank Safety configuration: ABS, brake pad wear alarm, seat belt alarm,
door lock reminder, self-adjusting brake arm, adjustable headlights |
[Body
configuration] |
Total
mass(Kg) | 18000 | Tank
volume (m3) | 9.58 |
Rated
load mass (Kg) | 7825,7890 | Dimensions | 9425*2500*3710mm |
Curb
weight (Kg) | 9980 | Tank size | 2770×2460×1580(3070×2460×1580) |
Rear
protection height from ground | 50 0mm | Tank material | National standard
carbon steel 4mm |
Rear
lower protection dimensions | 120×50(mm) | Fog cannon range
(optional) | 60-80m |
Water pump model | Hubei Tianyi 60-90 | PTO | Jiashan, Hangzhou |
Other
configurations: with front spray, rear
liquor, fire interface, self-flow valve, self-priming and self-draining,
other configurations are as standard |
