【 Technical Parameters 】 |
Product
trademark | Huatong
brand | product
name | Multifunctional
dust suppression vehicle |
Chassis
model | EQ1258GSZ6DJ | Product
number | HCQ5252TDYEQ6CS |
Axle
load(Kg) | 7000/18000
(two-axis group) | Maximum
speed (Km/h) | 89 |
Approach
angle/departure angle (°) | 29/12,29/13 | Front
suspension/rear suspension (mm) | 1475/3025,1515/2985 |
Number
of axes | 3 | Number
of tires | 10 |
Wheelbase | 4350+1350,4750+1350 | Tire
specifications | 11.00R20
18PR,295/80R22.5 18PR |
Number
of leaf springs | 8/10,9/10 | Fuel
type | diesel
fuel |
Front
wheelbase (mm) | 1860,1940,1960,1985,2010,2040 | Rear
wheelbase (mm) | 1750/1750,1860/1860,1880/1880 |
engine
model | YCS06245-60 | Engine
manufacturer | Guangxi
Yuchai Machinery Co., Ltd. |
Displacement
(ml) | 6234ml | Power(Kw) | 180kw |
gearbox | Shaanxi Fast
8-speed gearbox | front/rear axle | 5T/10T*2 |
Daliang | 280mm | Other
configurations | Air conditioning, air bag seats, central control,
multi-function steering wheel, driving recorder |
|
|
|
|
[Body
configuration] |
Total
mass(Kg) | 25000 | Tank
volume (m3) | 9.58 |
Rated
load mass (Kg) | 7370,7305 | Overall
dimensions (mm) | 11360x2520,2550x4000,3960 |
Curb
weight (Kg) | 17500 | Tank
size (mm) | 4000×2400×1350 |
Rear
protection height from ground | 490 mm | Tank material | National standard
carbon steel 4mm |
vertical lifting
height | 18m | Fog cannon range
(optional) | 80-100m |
Multi-way valve | Yangzhou Zhongmei | PTO | Jiashan, Hangzhou |
hydraulic lock | Yangzhou Zhongmei | Rotary reducer | Tai'an Today |
Rotary joint | Yangzhou Zhongmei | Oil cylinder | Hyperius |
Balance valve | Yangzhou Zhongmei | Proportional valve | Shanghainese |
Other
configurations | With front spray, rear liquor, fire interface,
self-flow valve, self-priming and self-draining, other configurations are as
standard |
|
|
|
|
|
|
|
|
|
|
|
|
