Dongfeng D9 square tank dust suppression 4500 wheelbase 80 meters fog gun

Product  trademark

Chengliwei  brand

product  name

Multifunctional  dust suppression vehicle

Chassis  model

EQ1185LJ9CDE

Product  number

CLW5180TDYD6

Axle  load(Kg)

6500/11500

Maximum  speed (Km/h)

105

Approach  angle/departure angle (°)

19/12,19/10

Front  suspension/rear suspension (mm)

1260/2500,1260/2740

Number  of axes

2

Number  of tires

6

Wheelbase

4500,4700

Tire  specifications

10.00R20  18PR,275/80R22.5 18PR

Number  of leaf springs

8/10+7,8/-

Fuel  type

diesel  fuel

Front  wheelbase (mm)

1862,1933,1949,1904

Rear  wheelbase (mm)

1806,1865

engine  model

B6.2NS6B230

Engine  manufacturer

Dongfeng  Cummins Engine Co., Ltd.

Displacement  (ml)

6200

Power(Kw)

1 69kw

gearbox

Shaanxi Fast  8-speed gearbox

front/rear axle

5T/10T

Other  configurations

Electronically controlled air conditioning, aluminum alloy wheels,  air brakes, LED daytime running lights, central locking, electric doors and  windows, remote control key, leather seats, LCD instrument panel, power  steering, clutch assist, exhaust brake, sunroof, aluminum Alloy fuel tank

Safety configuration: ABS, brake pad wear alarm, seat belt alarm,  door lock reminder, self-adjusting brake arm, adjustable headlights

[Body  configuration]

Total  mass(Kg)

18000

Tank  volume (m3)

8.64

Rated  load mass (Kg)

7825,7305

Dimensions

9220 ,  9750,10850x2550x3750

Curb  weight (Kg)

9980,10500

Tank size

2770×2460×1580(3070×2460×1580

Rear  protection height from ground

50 0mm

Tank material

National standard  carbon steel 4mm

Rear  lower protection dimensions

120×50(mm)

Fog cannon range  (optional)

50-80m

Water pump model

Hubei Tianyi 60-90

PTO

Jiashan, Hangzhou
