JAC 8 square sweeper

Wheelbase(mm)

38 45

tire

245/70R19.5,8.25R20

tire  quantity

7(including  1 spare tire)

Wheelbase

Front  wheel(mm)

1705

Rear  wheel(mm)

1785

Rated  occupants

3  people

Front  suspension/rear suspension (mm)

1075/2180

approach  angle

20 °

departure  angle

28 °

Height  from the ground (mm)

320

Rated  load mass (kg)

4355

Curb  weight (kg)

7120

Maximum  total mass (kg)

11920

Dedicated performance  parameters

Bin  volume (m ³ )

4 (stainless steel material)

Clean  water tank volume (m ³ )

4 (stainless steel material)

Cleaning  width (mm)

2800-3200

Cleaning  operation speed (km/h)

3-15

Cleaning  operation speed (km/h)

15-20

Maximum  cleaning capacity (m ² /h)

48000

suction  capacity

Density  (g/cm ³ )

2.0

Mass(kg)

1.5

Suction  particle size (mm)

≥100

Garbage  bin dumping angle

≥45°

Cleaning  efficiency

≥96%

Operation  noise (db)

< 88 Comply  with GB7258 regulations
