Dedicated
performance parameters | Bin
volume (m 3 ) | 7
(stainless steel material) |
Clean
water tank volume (m 3 ) | 9
(stainless steel material) |
Cleaning
width (mm) | 2800-3200 |
Cleaning
operation speed (km/h) | 3-15 |
Cleaning
operation speed (km/h) | 15-20 |
Maximum
cleaning capacity (m 2 /h) | 48000 |
suction
capacity | Density
(g/cm 3 ) | 2.0 |
Mass(kg) | 1.5 |
Suction
particle size (mm) | ≥100 |
Garbage bin dumping angle | ≥45° |
Cleaning efficiency | ≥96% |
Operation noise ( db ) | < 88 Comply with GB7258 regulations |
Driving
performance parameters | Drive type | 4×2 rear axle drive |
Suspension type | leaf spring |
Number
of leaf springs (front/rear) | 8/10+7 |
Braking
type | Dual
circuit pneumatic brake, drum type |
Braking distance (full load 30km/h) | ≤10m |
Maximum speed (km/h) | 99 |
Minimum turning radius (m) | 8 |
Maximum grade | ≥30% |
clutch system | Single-plate dry diaphragm spring clutch,
hydraulically operated |
transmission system | Mechanical 5-speed transmission with
synchronizer, manual |
Engine fuel consumption | Travel (L/100km) | Homework(L/h) | Operation(L/10000m 2 ) |
≤14 | ≤8 | ≤5 |
Dust
reduction system | water
spray form | low
pressure mist |
Main
components | Imported
high-pressure pumps, water filters, pipelines, stainless steel spray racks,
high-pressure nozzles, etc. |
High
pressure pumps | GTM |
Installation
location | Cleaning
and dust reduction | Scan the disk left and right |
Vacuuming
and dust reduction | Inside the suction cup suction port |
Control
type | Electronic control, one-button operation |
|
|
|
|
|
|
|
