serial
number | name | Model,
specifications | Belonging
system | Remark |
1 | Car
chassis | ZZ1317N466GF1 | Chassis | SINOTRUK HOWO/ 8×4 |
2 | engine | WP8.350E61 MC07H.34-60 | Weichai has 350 horsepower
and MAN has 340 horsepower. National VI |
3 | Asphalt
tank capacity | 10 cubic meters | Asphalt tanks, fiber
silos, stone silos | Inner tank volume |
stone silo | 14 cubic meters | internal lift |
4 | Fiber
bin | 1T |
|
5 | Thickness
of insulation layer | 50mm | Rock
wool insulation |
6 | Covered
in stainless steel | 1mm | 1
thick stainless steel plate |
7 | mixer | stand mixer | Motor imported from the
United States |
8 | PTO | Full power take-off | Source
of work motivation | Spraying can start from
zero |
9 | variable
piston pump | A10 series | Hydraulic
system | Germany Rexroth |
10 | Asphalt
pump motor | HZH05-110BD40 | Ningbo |
11 | Hydraulic valve system | CLW520-2 | Germany Rexroth |
12 | asphalt
pump | K244 American Viking/TGGP185-125
Belgium | asphalt sprinkler
system | Available in USA or
Belgium |
13 | Number
of nozzles | 64 imported seals | The
control method is: 1 control 1 |
14 | burner | G20 (200,000 kcal/hour) | Heating
system | Two imported from Italy |
15 | Thermal
oil pump | RY32-32-160 | Hebei |
16 | Thermal
oil pump motor | G5-08 | Tianjin Tianji |
17 | Stone spreading method | gravity flow | Stone chip spreading
system | 16-way material door
(computer controlled) |
18 | stone door control | Electric push rod fine
adjustment | Well-known domestic brands |
19 | Fiber spreading system | Two sets of spreaders |
| Cheng Li |
20 | 32 cutters |
| Imported blade |
twenty one | drive motor |
| Eaton, USA |
twenty two | Control
system method | Cab touch screen computer
control + rear working platform control (standby) | Control System | The control system adopts:
German Siemens modular design, with faster and smoother operation and low failure
rate. Optional special controller for construction
machinery is available. |
twenty three | speed
sensor | Ni5-G12 | Turk,
Germany |
twenty four | Temperature Controller | Pt100 | Shanghai |
25 | monitor | set |
| Domestic |
