serial
number | name | quantity | Supplier/Model |
1 | Car chassis | 1 | Dongfeng Tianjin 4X2 |
2 | Hydraulic pump | 1 | Special fine |
3 | cement motor | 1 | Eaton |
5 | Belt conveyor reduction
motor | 1 | Han Bamboo |
6 | Paving box/asphalt pump
motor | 3 | Eaton |
7 | Asphalt, water level gauge | 2 | Vidias |
8 | Stirring motor | 1 | Hanzhu Hydraulic |
9 | Control Valve |
| Germany Rexroth |
10 | Hydraulic accessories | 1 | Germany Rexroth |
11 | asphalt pump | 1 | USA |
12 | water flow meter | 1 | Shanghai |
13 | water pump | 1 | Cheng Liwei |
Product
main configuration
14 | High pressure pumps | 1 | Shanghai |
15 | Vibration motor | 1 | Wolong |
16 | Control System | 1 | Chengliwei special
controller |
17 | mixer | 1 | Cheng Liwei |
18 | paving box | 1 | Cheng Liwei |
19 | sensor | 1 | Turk, Germany |
Product Specifications
category | project | unit | parameter |
emulsified asphalt system | emulsified asphalt tank | l | 2200 |
Maximum asphalt flow | l/min | 270 |
Measurement method | / | Hall sensor/pump speed adjustment |
Asphalt pump insulation method | / | Hot water insulation |
water system | water tank | L | 2200 |
maximum water flow | L/min | 350 |
Measurement method | / | Flowmeter display/pump speed
adjustment/valve adjustment |
stone system | Stone warehouse (full warehouse) | M ³ | 7.5 |
Conveyor belt bandwidth | mm | 550 |
Stone conveying capacity | kg/min | 2200 |
Adjustment method | / | Speed adjustment |
Anti-clogging device | / | DC vibration motor |
Stirring system | Stirring ability | Kg/min | 1800-2200 |
Stirring form | / | Double shaft powerful mixing |
paving box | Paving width | m | 2.5--3.7 |
system | Width adjustment method | / | Hydraulic telescopic adjustment |
Paving thickness | mm | 3--15 |
Speed adjustment | / | Hydraulic adjustment |
Auxiliary scraping device | / | Second scraping |
Cleaning system | Cleaning method |
| High pressure cleaning |
Control System | Microcomputer PLC | / | Chengliwei special controller |
| control method | / | Manual / Auto |
Chassis | model | / | DFH1180EX8 |
Manufacturer | / | Dongfeng Commercial Vehicle Co., Ltd. |
top speed | km/h | 89 |
Drive type | / | 4X2 driver |
front/rear suspension | mm | 1 430 /2640 |
Wheelbase | mm | 5000 |
Approach / departure angle | ° | 21/10 |
minimum ground clearance | mm | 460 |
Tire specifications | / | 10.00R20 18PR |
Engine horsepower |
| Cummins 230 HP |
Emission Standards | / | Euro 3 |
