V362 automatic ambulance vehicle technical parameters
serial number | category | Parameter(1) |
1 | Vehicle
model | CLW5033XJH6DP |
2 | Chassis
model | JX6533PA-M6 |
3 | Body size
(mm) | 5341×2032×2465 |
4 | Internal dimensions (mm) | 2600×1730×1720 |
5 | Body
structure | Load-bearing |
6 | Total mass
(kg) | 3300 |
7 | curb weight | 2290 |
8 | engine model | ECOBOOST4G20B6L |
9 | Fuel type | gasoline |
10 | Displacement
(ml) | 1997 |
11 | Emission
Standards | GB18352.6-2016
Country VI |
12 | Rated power
(kw) | 149 |
13 | Wheelbase
(mm) | 3300 |
14 | Front
suspension/rear suspension (mm) | 1014/1027 |
15 | Front
wheelbase/rear wheelbase | 1736/1720 |
16 | Suspension
type | Front:
MacPherson independent suspension Rear: leaf
spring non-independent suspension |
17 | Drive mode | wheel drive |
18 | gearbox | 6-speed automatic
manual |
19 | Brake type | front
disk rear disk |
20 | Maximum
speed (km/h) | 156 |
twenty
one | Tire
specifications | 215/75R16LT |
twenty
two | Rated
passenger capacity (person) | 7.8 |
twenty
three | Anti-lock
braking system | Configuration |
twenty
four | Central
locking/remote key in car | Configuration |
25 | Door opening
method | Rear: 180° double doors Side: Manual
side sliding door |
2 6 | Fuel
consumption | 8.1 per 100
kilometers |
Transfer ambulance medical cabin configuration list
| 1 | Medical cabin air conditioner |
| 2 | Medical cabin heater |
Circuits and electrical appliances |
Alarm, warning system | 1 | Long row of standard police lights, |
2 | 100W siren and handheld control |
Inner roof, interior, power supply | 3 | 500W power inverter |
4 | Medical cabin rocker control switch |
5 | 1 220V power port, 1 12V power supply |
6 | 2 top lights |
7 | Long disinfection lamp |
Oxygen path and oxygen |
oxygen supply system | 1 | 1 10-liter medical iron bottle and
shock-absorbing clamp |
2 | 1 humidification bottle with oxygen
pressure reducing valve, directly connected to the oxygen bottle |
Medical cabin production |
Inside the medical cabin | 1 | Original car interior |
2 | middle partition wall |
3 | Sliding observation window in the middle
partition wall |
4 | A small medicine bottle cabinet behind the
middle partition wall |
5 | Fixed oxygen bottle next to medicine bottle
cabinet |
6 | Bench seat belt and seat belt embedded |
7 | Blue medical floor leather |
seat |
Seating system |
V362 gasoline automatic transfer ambulance-Details
