brand

Shanqi

model

WP10HNG350E60

engine

WP10HNG350E60 engine Euro III

gearbox

10 gears

Wheelbase

1800+3375+1400

Drive axle

MCX16ZG double bridge (drum)

Maebashi

VGD95 front axle (drum)

tire

11.00R20 18PR

bumper

high position

tank

400L

Drive form

8x4

Tank and body configuration parameters

Effective volume of tank (m³)

16

Tank material

Q355( 6 mm)

Header

Q355( 7mm )

blade

Double spiral curved surface + wear-resistant strip (3mm)

pumps, motors

CSIC90/INTPAP90

Reducer

PMP/Bonfiglioli

heat sink

Xinxiang Jiuhe 18L

Front and rear supports

Plate box structure

In and out of hopper

Q345 manganese plate production

Discharge chute

Equipped with an extended auxiliary chute that can rotate 180 degrees horizontally

water supply system

Large capacity air pressure water tank (300L)

Control method

Trinity (cab, rear sides)

Rotation speed (r/min)

0-14

Concrete slump (mm)

70-260

Tilt angle (°)

11.8

Discharge residual rate (%)

≤1

Top painting

Primer

Iron red acrylic

Medium coating

High gloss gray

Topcoat

polyurethane
