Overall machine performance parameters
Product model: CLW5180GLQD6
Total mass: 18000kg
Curb weight: 9552kg
Overall dimensions: 8800×2500×3100mm
Spreading width: 4500mm
Nozzle spacing: 125mm
Asphalt spreading amount: 0.3～3.5L/m 2
Working speed: 1.5--20km/h
Heating method: Diesel burner imported from Italy (200,000 kcal/hour)
Spraying medium: hot asphalt, SBS modified asphalt, emulsified asphalt, modified milk asphalt.
Spreading error: ±2%
The main accessories parameters are shown in the table below:
serial number | name | Model, specifications | Belonging system | Remark |
1 | Car chassis | DFH1180EX8 | Chassis |
|
2 | engine | B6.2NS6B210 | Cummins 6 cylinder 210 HP |
3 | Asphalt tank capacity | 12 cubic meters | tank | High quality carbon steel |
4 | Thickness of insulation layer | 40mm | Rock wool insulation |
5 | Covered in stainless steel | 1mm | 1 thick stainless steel plate |
6 | PTO | Special for spreader truck | work motivation |
|
7 | Hydraulic pump | CBQ550-L | Hydraulic system | Tianjin |
8 | Proportional valve | EFBG-03-160-HF | Taiwan |
9 | Asphalt pump motor | 05- 130- BD31 | Tianjin/ Ningbo |
10 | asphalt pump | QGB 950 | Asphalt Spraying System | Shanggui, 950 L/min |
11 | Number of nozzles | 36 | The control method is: 1 control 1 |
12 | hand spray gun | 5m hose + handheld spray boom | Filling the corners |
13 | burner | G20 (200,000 kcal/hour) | Heating system | Riallo, Italy |
14 | Thermal oil pump | RY 25-25-160 | Hebei |
15 | Thermal oil pump motor | 380V-2.2KW-2 pole | Lu'an, Anhui |
16 | Control system method | Cab touch screen computer control + rear working platform control (standby) | Control System | The control system adopts: Siemens modular design, which runs faster and smoother and has a low failure rate. |
17 | speed sensor | Ni5-G12 | Turk |
18 | Temperature Controller | WZP-230 | Shanghai |
19 | dynamo | 6 KW gasoline generator | Power Systems | Domestic |
