Total mass: 18000kg
Curb weight: 9888kg
Overall dimensions: 8950×2500×3150mm
Spreading width: 4500mm
Nozzle spacing: 125mm
Asphalt spreading amount: 0.3～4.0L/m 2
Working speed: 1.5--20km/h
Heating method: Diesel burner heating in Riello, Italy (200,000 kcal/hour)
Spraying medium: hot asphalt, SBS modified asphalt, emulsified asphalt, modified milk asphalt.
Spreading error: ±2%
The main accessories parameters are shown in the table below:
serial number | name | Model, specifications | Belonging system | Remark |
1 | Car chassis | ZZ1187K561DF1Z | Chassis | SINOTRUK HOWO 4×2 |
2 | engine | WP4.6NQ220E61 | Weichai 220 horsepower |
3 | Wheelbase | 5200mm |
|
3 | Asphalt tank capacity | 12 cubic meters | tank | High quality carbon steel |
4 | Thickness of insulation layer | 50mm | Rock wool insulation |
5 | Covered in stainless steel | 1mm | 1 thick stainless steel plate |
6 | PTO | Special for spreader truck | work motivation |
|
7 | Hydraulic pump | CBQ550-L | Hydraulic system | Hefei Changyuan |
8 | Proportional valve | EF RD - G 03-160-5-31 | Northman |
9 | Solenoid directional valve | SWH-G03-D24-20 | Northman |
10 | relief valve | MT-02 | Northman |
11 | heat sink | AH1012T | Hercules |
12 | Asphalt pump motor | HZH 05- 110 BD31 | Ningbo Han Bamboo |
13 | asphalt pump | QGB 950 | sprinkler system | Shanggui, 950 L/min |
14 | Number of nozzles | 36 | The control method is: 1 control 1 |
15 | hand spray gun | 5m hose + handheld spray boom | Filling the corners |
16 | burner | G20 (200,000 kcal/hour) | Heating system | Riallo, Italy |
17 | Thermal oil pump | RY32-32-160 | Hebei |
15 | Thermal oil pump motor | GM05 | Tianjin Tianji |
16 | Control system method | Cab touch screen computer control + rear working platform control (standby) | Control System | The control system adopts: American Xelinzhuo special controller/Germany Siemens special controller, which runs faster and smoother and has a low failure rate. |
17 | speed radar | Ni5-G12 | Turk |
18 | Temperature Controller | PT100 | Shanghai |
19 | dynamo | LT10000EN3-4 | Power Systems | Lutian 6kw gasoline generator |
