Dongfeng 12-party oil tanker

Quality parameters

Axle weight(kg)

6500/11500

Maximum total mass  (kg)

18000

Vehicle curb weight (kg)

7455

Size parameters

Length (mm)

7635

Wheelbase (mm)

4700

Width (mm)

2500

rear suspension

2210

Height (mm)

3100

rear wheelbase

18 00

front overhang

Chapter 1475

departure angle

12

Front track

1910

approach angle

twenty three

Other parameters

Maximum speed (km/h)

80

Number of passengers  allowed

2 or 3 people (including driver)

Number of leaf springs

8/10+7

Drive form

4×2

tire quantity

6

Tire specifications

10.00R20 18PR

※ Chassis

Shape model

EQ1188GSZ6DJ

manufacturer

Guangxi Yuchai Machinery Co., Ltd.

※ Cab configuration

Air conditioner

Heating and cooling air conditioning

central locking

have

electric glass

have

air brake

have

Orientation assistance

have

※ Engine

Model

YCS04200-68

Power(kw)/horsepower

147/2 00

manufacturer

Guangxi Yuchai Machinery Co., Ltd.

Displacement (ml)

4156

※

8 gears

※other

brake

air brake

turn

power steering

Voltage (volts)

twenty four

ABS

have

12.6 square meters, Q235B plate, 5mm thick  cylinder, 5mm thick head, 5mm thick partition, single warehouse, first tank  mouth on the top of the tank, customized European standard, 1 submarine voice  alarm device with valve, with 80/60 special Oil pump (can pump in and out),  (optional high-flow oil dispenser and 15-meter thick reel and gun), rear  ladder, manual guardrail, tool box, rear bumper, side guardrail
