[Chassis information] |
end plate | Dongfeng/ EQ1125SJ8CDC | Wheelbase | 3800mm |
engine | Guangxi Yuchai YCY30165-60 | power | Yuchai 12 1 k w |
Drive
type | Rear
wheel drive | Dimensions | 6960*2200*2810 |
【 Tank 】 |
Water tank material | High-quality
steel plate with high-tech anti-corrosion treatment | Foam
tank: | High
quality 304 stainless steel |
capacity: | Water: 5000 Kg |
|
|
[ Fire pump and piping system ] |
fire
pump brand | Shanghai
Rongshen | Fire
pump model | CB15/30 low pressure fire pump |
fire pump pressure | 1.0MPa | Fire pump flow | 20L/s |
Installation
type | rear | Water
diversion time | ≤35s |
Pump
material | Wear-resistant
and corrosion-resistant to meet sealing requirements | Maximum
vacuum degree | ≥85kPa |
Water absorption depth | ≥7m | Vacuum
pump | Piston , |
【 Fire cannon 】 |
model | PS 3 0 type fire monitor | pressure | 1.0MPa |
range | Water ≥ 45 m | Location | on
top of the jug |
control | Manual control with locking mechanism |
【 PTO 】 |
Type | Full
power sandwich power take- off | cooling
method | Forced
water cooling |
[ Equipment box and pump room ] | The frame and skin are made of high-quality carbon
steel; the internal equipment rack is made of aluminum alloy profiles, and
the interior panels are oxidized aluminum plates |
【 Electrical system 】 | 1.
The top of the cab is equipped with a long row of red luxury police lights. |
2.
The alarm power is 100W; |
3.
In order to ensure safe use, the entire vehicle line is made of an integral
wiring harness, and waterproof plugs are used at the connections to ensure
line safety during use. |
4. The roof of the vehicle is equipped with a
fire scene lighting lamp ; safety
sign lights are provided below both sides of the vehicle, and reflective
signs are affixed to the body and rear as standard. |
5.
All equipment boxes are equipped with LED lighting to facilitate night combat
lighting. |
6.
There are two strobe lights on each side of the vehicle, and safety sign
lights and side retroreflectors are installed below. (Combined
type ) , equipped with front and rear side lights, one turn signal on each
side, and lights in the passenger compartment, equipment box, and pump room . |
7.
The sirens, warning lights, strobe lights, and circuits are independent
additional circuits, and the control devices are installed in the cab. |
8.
All lines are protected by sleeves, and different colors are used to
distinguish the connection forms and functions of the lines. |
9.
Equipment on the dashboard in the pump room: liquid level gauge, tachometer,
pressure gauge, vacuum gauge, equipment box lighting switch, etc. |
[ Dashboard and on-board equipment ] | 1.
The instrument panel is located in the pump room at the rear of the vehicle,
with a control panel and sufficient lighting; |
2.
All control handles, switches, and indicator lights have Chinese logos near
them; |
3.
There are instructions for operating steps. |
4.
All signs have durability and high adhesion, and can withstand the impact of
drastic changes in temperature and climate. |
5.
The operation panel is made of high-quality aluminum plate, which is
beautiful, durable and light in overall weight. |
6.
The operating system of the pump room is set at the rear of the vehicle, with
no pressure outlet to ensure the safety of the operator, and with panel
lighting. |
