Heavy Vehicle Haworth 50-ton towing and lifting one-piece barricade truck

Quality parameters

Axle load(kg)

8500/8500/13000/13000

Maximum total mass  (kg)

43000

Vehicle curb weight (kg)

23210

Size parameters

Length(mm)

11700

Wheelbase (mm)

1950+4600+1400

Width (mm)

2 550

Rear suspension

2 275

Height(mm)

3250

rear wheelbase

1860

front overhang

1 500

departure angle

twenty one

Front track

2022

approach angle

17

Other parameters

Maximum speed (km/h)

95

Allowed number of  passengers

2, 3 (including driver)

Number of leaf springs

8/10+7

Drive form

4×2

Number of tires

12

Tire specifications

12.00R20 20PR

※Chassis

Chassis model

ZZ5437V4667F1

Manufacturer

China National Heavy Duty Truck  Group Co., Ltd.

※ Cab configuration

air conditioner

Heating and cooling air conditioning

central locking

have

electric glass

have

air brake

have

Directional assistance

have

※engine

model

MC11.40-60

Power(kw)/horsepower

297/400

Manufacturer

China National Heavy Duty Truck  Group Co., Ltd.

Displacement (ml)

10518

※Transmission

10 gears

※other

brake

air brake

turn

power steering

Voltage (V)

twenty four

ABS

have

25T20D bodywork, imported hydraulic system, two-section hexagonal boom,  25-ton three-section support arm, split carriage, bilateral linkage operating  device, two ten-ton hydraulic winches, 45-meter steel wire rope, diameter  18MM, equipped with Four sets of steel forks, one set of tow fork cover, one  set of steel lifting lug tow fork, one set of tire holding device. One long  row of engineering warning lights. One set of auxiliary lights, one set of  auxiliary air pipe assembly, and two binding chains
