Sprinkler truck technical specifications
※Basic technical parameters of the vehicle : | ||||
Quality parameters | Rated loading mass (kg) | 14205 | Axle load(kg) | 7000/18000 |
Vehicle curb weight (kg) | 10600 | |||
Maximum total mass (kg) | 25000 | |||
Size parameters | Length(mm) | 10375 | Wheelbase (mm) | 4375+1350 |
Width (mm) | 2550 | |||
Height(mm) | 3450 | |||
front overhang | 1450 | Rear suspension | 3200 | |
Front track | 1900 | rear wheelbase | 18 60 | |
approach angle | twenty three | departure angle | 9 | |
Other parameters | Maximum speed (km/h) | 85 | Allowed number of passengers | 2, 3 (including driver) |
Number of leaf springs | 8/10+7 | Drive form | 4×2 | |
Number of tires | 6 | Tire specifications | 10.00R20, 275/80R22.5 18PR |
