Sprinkler truck technical
specifications
※Basic technical parameters of the
vehicle : |
Quality parameters | Rated loading mass (kg) | 10680 | Axle load(kg) | 6500/11500 |
| Vehicle curb weight (kg) | 7125 |
|
|
| Maximum total mass (kg) | 1 8000 |
|
|
Size parameters | Length(mm) | 8500 | Wheelbase (mm) | 3950 |
| Width (mm) | 2500 |
|
|
| Height(mm) | 3100, 3300 |
|
|
| front overhang | 1 445 | Rear suspension | 2 555 |
| Front track | 1940 | rear wheelbase | 18 60 |
| approach angle | 1 8 | departure angle | 13 |
Other parameters | Maximum speed (km/h) | 90 | Allowed number of
passengers | 2, 3 (including driver) |
| Number of leaf springs | 8/10+7 | Drive form | 4×2 |
| Number of tires | 6 | Tire specifications | 10.00R20, 275/80R22.5
18PR |
※Chassis |
Chassis model | LZ1186M3ACT |
Manufacturer | Dongfeng Motor Co., Ltd. |
※ Cab configuration |
air conditioner | Heating and cooling air conditioning | central locking | have |
electric glass | have | air brake | have |
Directional assistance | have |
|
|
※engine |
model | YCS04200-68 | Power(kw)/horsepower | 147/200 |
Manufacturer | Guangxi Yuchai Machinery Co., Ltd. | Displacement (ml) | 4156 |
Rated speed (r/min) | 2300 |
Maximum torque (N ∙ m) | 720 |
Maximum torque speed (r/min) | 1600 |
Emission Standards | GB3847-2005, GB17691-2018 Country VI |
※Transmission |
brand | Eighth gear |
※other |
brake | air brake |
Voltage (V) | twenty four |
turn | power steering |
ABS | have |
※Complete vehicle structure |
|
|
