※engine |
model | YCS04200-68 | Power(kw)/horsepower | 147/200 |
Manufacturer | Guangxi Yuchai Machinery Co., Ltd. | Displacement (ml) | 4156 |
Rated speed (r/min) | 2300 |
Maximum torque (N ∙ m) | 720 |
Maximum torque speed (r/min) | 1600 |
Emission Standards | GB3847-2005, GB17691-2018 Country VI |
※Transmission |
brand | Shaanxi gear small eight gears |
※other |
brake | air brake |
Voltage (V) | twenty four |
turn | power steering |
ABS | have |
※Complete vehicle structure |
|
|
※Tank body |
| Water tank capacity (L) | 10000-12000 | Tank material | Q235 carbon steel |
| Thickness(mm) | 4 | shape | Square and round tank |
| structure | Welded | Anti-sway board | vertical |
| manhole | One DN460 manhole with quick
locking/opening device |
Schematic diagram of tank structure | (1) Head (2) Upper guardrail
(3) Tank mouth (4) Ladder (5) Lifting lugs (6) Support (7) Sub-beam (8)
Barrel (9) Gun barrel (10) Wave-proof partition (11) Measuring tube |
Materials and craftsmanship | ◇High-pressure gas leak testing after
the tank is formed, so that the tank has the characteristics of high
strength, stable center of gravity, stable and safe vehicle transportation; ◇The tank body is automatically welded
by gas shielded welding at the welding station to ensure the original quality
of the tank weld seam. ◇The length of the tank is welded with
one-time formed integral longitudinal beams to ensure the strength of the
tank. ◇Carry out overall shot peening
process to eliminate weld stress and remove overall rust. |
※High pressure water pump (standard
configuration) |
| model | 80QZ60/90N(S) |
| Manufacturer | Suizhou Yifeng Pump Industry
Co., Ltd. |
| flow | 60 m3/h | Lift(m) | 90 |
| Self-priming height (m) | 6.5 | Self-priming time (m in/8m) | 1 |
| Shaft power(KW)m | 22.5 | Input shaft speed (min) | 1180 |
Features | ◇80QZ60/90N(S) pump is a self-priming
centrifugal pump with a speed increase box. It is mainly composed of a pump
body, impeller, mechanical seal, shaft, speed increase box and other
components. ◇The power required for pump operation
is directly provided by the car engine through the power take-off. As a
ground pumping station, it can also be driven by a motor or diesel engine. ◇When the water source contains
sediment and debris, the inlet of the suction pipe should be placed in the
mesh cover. The total area of the mesh cover's through holes should be
greater than 300cm2, and the mesh diameter should be less than 6mm. ◇The pump shaft seal adopts mechanical
seal, so the pump operates reliably and has a long life. |
※Forward thrust |
It comes standard with a front
hedging cone nozzle. The flushing width is ≥ 24m. The angle of the cone nozzle can be adjusted
arbitrarily. It can flush the garbage in the middle lane to both sides,
making it easier to clean and collect the garbage. At the same time, it can
spray water and reduce dust on multiple lanes. |
