end   plate

Benz

Wheelbase

1800+4500+1350mm

engine

Mercedes-Benz OM471LA

power

333kW

Drive type

Rear wheel drive

【Tank】

[ Fire   pump and piping system ]

fire pump pressure

1.0MPa

Fire pump flow

60L/s

Installation type

rear

Water diversion time

≤35s

Pump material

Wear-resistant and corrosion-resistant to meet sealing requirements

Maximum vacuum degree

≥85kPa

Water absorption   depth

≥7m

Vacuum pump

Piston type ,   vacuum pumps are preferably electric   vacuum water diversion pumps of the same brand as fire pumps.

【Fire   cannon】

brand

west

model

PS20 type   fire monitor

range

Water ≥   45 m

pressure

1.0MPa

Location

on top of the jug

control

It adopts manual control and has a locking mechanism.

【PTO】

Type

Full power sandwich power take- off

cooling method

Forced water cooling

[Equipment box and pump room]

The frame and skin are made of high-quality carbon   steel; the internal equipment rack is made of aluminum alloy profiles, and   the interior panels are oxidized aluminum plates

【 Electrical system 】

1. The top of the cab is equipped with a   long row of red luxury police lights.

2. The alarm power is 100W;

3. In order to ensure safe use, the entire   vehicle line is made of an integral wiring harness, and waterproof plugs are   used at the connections to ensure line safety during use.

4. The   roof of the vehicle is equipped with a fire scene lighting lamp ; safety sign lights are provided below both   sides of the vehicle, and reflective signs are affixed to the body and   rear as standard.

5. All equipment boxes are equipped with LED   lighting to facilitate night combat lighting.

6. There are two strobe lights on each side   of the vehicle, and safety sign lights and side retroreflectors are installed   below.

(Combined type ) , equipped with front   and rear side lights, one turn signal on each side, and lights in the   passenger compartment, equipment box, and pump room .

7. The sirens, warning lights, strobe   lights, and circuits are independent additional circuits, and the control   devices are installed in the cab.

8. All lines are protected by sleeves, and   different colors are used to distinguish the connection forms and functions   of the lines.

9. Equipment on the dashboard in the pump   room: liquid level gauge, tachometer, pressure gauge, vacuum gauge, equipment   box lighting switch, etc.

[ Dashboard and on-board equipment ]

1. The instrument panel is located in the   pump room at the rear of the vehicle, with a control panel and sufficient   lighting;

2. All control handles, switches, and   indicator lights have Chinese logos near them;

3. There are instructions for operating   steps.

4. All signs have durability and high   adhesion, and can withstand the impact of drastic changes in temperature and   climate.

5. The operation panel is made of   high-quality aluminum plate, which is beautiful, durable and light in overall   weight.

6. The operating system of the pump room is   set at the rear of the vehicle, with no pressure outlet to ensure the safety   of the operator, and with panel lighting.
