serial number | name | quantity | Supplier/Model |
1 | Car chassis | 1 | Sinotruk Howo |
2 | Auxiliary engine | 1 | Cummins 140 HP |
3 | Hydraulic pump | 2 | pike |
4 | Cement box motor | 1 | Eaton/Danfoss |
5 | Belt conveyor reduction motor | 1 | Han Bamboo |
6 | Paving box/asphalt pump motor | 3 | Eaton/Danfoss |
7 | Asphalt, water level gauge | 2 | Vidias |
8 | Stirring motor | 1 | Eaton/Danfoss |
9 | Control Valve | Germany Rexroth | |
10 | Hydraulic accessories | 1 | Germany Rexroth/Taiwan Northern Precision Machinery |
11 | asphalt pump | 1 | American Weeknd |
12 | water flow meter | 1 | Shanghai |
13 | water pump | 1 | Cheng Liwei |
14 | High pressure pumps | 1 | Shanghai |
15 | Vibration motor | 1 | Wolong |
16 | Control System | 1 | Chengliwei special controller |
17 | stir pot | 1 | Cheng Liwei |
18 | paving box | 1 | Cheng Liwei |
19 | sensor | 1 | Turk, Germany |
Product Specifications
category | project | unit | parameter |
Auxiliary power system
| factory | / | Cummins |
Output Power | kw/(r/min) | / | |
Drive mode | / | Fully hydraulic drive | |
emulsified asphalt system
| emulsified asphalt tank | l | 4200 |
Maximum asphalt flow | l/min | 270 | |
Measurement method | / | Hall sensor/pump speed adjustment | |
Asphalt pump insulation method | / | Hot water insulation | |
water system
| water tank | L | 4200 |
maximum water flow | L/min | 350 | |
Measurement method | / | Flowmeter display/pump speed adjustment/valve adjustment | |
stone system
| Stone warehouse (full warehouse) | M³ | 14 |
Conveyor belt bandwidth | mm | 550 | |
Stone conveying capacity | kg/min | 2200 | |
Adjustment method | / | Speed adjustment | |
Anti-clogging device | / | DC vibration motor | |
cement system
| cement silo | M³ | 0.5 |
Cement delivery volume | kg/min | 10-60 | |
Adjustment method | / | Spiral speed adjustment | |
Anti-clogging device | / | shift fork | |
Stir system | Stirring ability | Kg/min | 1800-2200 |
Stirring form | / | Double shaft powerful mixing | |
Paving box system | Paving width | m | 2.5--4.2 |
Width adjustment method | / | Hydraulic telescopic adjustment | |
Paving thickness | mm | 3--15 | |
Speed adjustment | / | Hydraulic adjustment | |
Auxiliary scraping device | / | Second scraping | |
Clean system | Cleaning method | / | High pressure cleaning |
control system | Microcomputer PLC | / | Chengliwei special controller |
control method | / | Manual / Auto | |
Chassis
| model | / | SX1319MB6F1 |
Manufacturer | / | China National Heavy Duty Truck Group Jinan Truck Co., Ltd. | |
top speed | km/h | 89 | |
Drive type | / | 8×4 dual rear axle drive | |
Minimum turning diameter | m | 14.6 | |
front/rear suspension | mm | 1525/2655 | |
Wheelbase | mm | 1800+3000+1400 | |
Wheelbase (front) | mm | 2011/2011 | |
Wheelbase (rear) | mm | 1860/1860 | |
Approach / departure angle | ° | 16/18 | |
minimum ground clearance | mm | 450 | |
Tire specifications | / | 11.00R20 18PR | |
power | kw | 257/7800 | |
Emission Standards | / | Country VI | |
other | Overall vehicle dimensions | mm | 11255x2550x3535 (length x width x height) |
Full load quality | kg | 31000 | |
Curb weight (empty) | kg | 16800 |
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
